chemical dosing system ensures precise, real-time control of water treatment processes. Equipped with sensors and PLC technology, it dynamically adjusts chemical feed rates based on pH, turbidity, and flow data, optimizing efficiency and reducing waste. Ideal for municipal/industrial wastewater plants, it minimizes manual intervention, cuts operational costs, and ensures compliance with environmental standards. Robust design, user-friendly interface, and remote monitoring capabilities guarantee reliable 24/7 performance.
Polymer Dosing Device
Function with dosing, mixing, conveying and automatic controlling, QK-JY auto dosing machine is widely used for raw water treatment of power plants, boiler feedwater treatment, oilgathering dewater treatment, all kinds of chemical dosing and wastewater treatment, also can be used for automatic dosing of coagulate, phosphate removing agent, ammonia, whitewash, corrosion inhibitor antisludging agent, etc.
Advantages of Flocculant Dosing Systems
● KPL automatic control system, easy operation;
● Stable working performance, alarm rising and stop working when fault goes;
● 304 Stainless steel ;
● Compact structure, small foot print;
Application：
Features Highly automatic control, KPL control system, easy handle. Special design Multi blade mixer. Compact structure, less room occupied, simple installation. In condition of certain output and continuous working, the chemical ready time is about 1 hour, density about 0.1%-0.3%. High stability, it will give alarm and stop working when it goes faul.
| Model | Capacity (L/h) | Mixing motor (kW) | Dosing motor (kW) | Dimensions(mm) |
| QK-JY500 | 500 | 0.37 | 0.4*3 | 1500*1000*900 |
| QK-JY1000 | 1000 | 0.37 | 0.55*3 | 2000*1000*900 |
| QK-JY1500 | 1500 | 0.37 | 0.75*3 | 2400*1000*900 |
| QK-JY2000 | 2000 | 0.37 | 0.75*3 | 2400*1000*1000 |
| QK-JY3000 | 3000 | 0.37 | 0.75*3 | 3000*1200*1000 |
| QK-JY4000 | 4000 | 0.37 | 1.1*3 | 3000*1200*1200 |
| QK-JY5000 | 5000 | 0.37 | 1.1*3 | 3000*1500*1200 |
| QK-JY6000 | 6000 | 0.37 | 1.5*3 | 3500*1500*1200 |
| QK-JY8000 | 8000 | 0.37 | 1.5*3 | 4000*1600*1400 |
| QK-JY10000 | 10000 | 0.37 | 2.2*3 | 5000*2000*1500 |
Requested Information before Quote
| Raw wastewater Quality | |
|
Wastewater source |
|
|
Treatment Capacity |
|
|
COD (mg/L) |
|
|
BOD (mg/L) |
|
|
SS (mg/L) |
|
|
Ammonia (mg/L) |
|
|
Phosphorus (mg/L) |
|
|
Other Values |
|
|
|
|
|
Treated Water Quality /Discharge Standard |
|
|
COD (mg/L) |
|
|
BOD (mg/L) |
|
|
SS (mg/L) |
|
|
Ammonia (mg/L) |
|
|
Phosphorus (mg/L) |
|
|
Other Values |
|
