Fenton Reactor

Fenton reactor in advanced oxidation process

QK Fenton reactor developed from traditional Fenton reactor by improving technique and optimizing process design. It eliminate shortage of more space occupied and high founding & running cost, replace traditional oxidant to composite oxidant which is more efficiency. Aim to meet continuous increasing discharge standard, the high-tech QKFT was created, and widely used for pretreatment or tertiary treatment of all kinds of industrial wastewater treatment plants.

Working principle

QK Fenton reactor consist of chemical mixing tank and reaction tank, linked with an overflow channel, wastewater flow into chemical fixing tank and outlet from reaction tank. An aeration device is installed on bottom of chemical fixing tank, a dosing pipe installed above chemical fixing tank and linked to composite oxidant dosing can. A mixer is installed in reaction tank, to help fully mixing. The effluent from reaction tank flow to setting tank for solid-liquid separation.

Features:

● Can be used both for tertiary treatment to remove refractory organic matter, and pretreatment to increase B/C ratio of wastewater treatment;

● Compact structure, auto controlling, easy handle, energy saving;

● Less space occupied, lower founding cost;

● Less chemical consumption, lower running cost.

Material:

Stainless steel 304 or anticorrosion carbon steel with zinc coating
